Material
RVS AiSi 304 polished
Cr |
Ni |
Cmax |
Si
max |
Mn |
18
20 |
8
10,5 |
0,08 |
1,00 |
2,00 |
Tensile
strength: 500 - 700 N/mm2
0.2 limit of elasticity :195 N/mm2
Surface
Polished grain : 320
Polishing direction : 2507 mm direction
Useable on 1 side
Protective film
Fire Resistance : non flammable ( DIN 4102 )
| Measurements |
| |
|
tolerations |
Length
Width
Construction length
Ridge height
Ridge length
Panel thickness
Squareness
Surface area
Weight
No. of ridges
Fold direction
( also possible in length direction upon request, max 2500 mm )
|
: 2507 mm
: 1250 mm
: 2.492,6 mm
: 6 mm
: 14,4 mm
: 0,8 mm
: -
: 3,1 m2
: 25,3 kg/st
: 8 kg/m2
: 172
: 1250 mm direction |
±
2 mm
± 1 mm
± 0,2 mm
± 01,5 mm
DIN
± 0,3 % on L
|
Treatments
  |
