Material
Aluminium AlMg1
|
|
|
|
|
|
|
|
0,30 |
0,45 |
0,05 |
0,15 |
0,7
1,1 |
0,10 |
0,20 |
- |
Tensile
strength: 140 - 180 N/mm2
0.2 limit of elasticity :120 N/mm2
Surface
Anodisation : 20 micron
type : E6 EV1
Chemically treated
Natural colour - matt
No anodisation points visible
Fire Resistance : non flammable ( DIN 4102 )
| Measurements |
| |
|
tolerations |
Length
Width
Construction length
Ridge height
Ridge length
Panel thickness
Squareness
Surface area
Weight
No. of ridges
Fold direction
( also possible in length direction upon request, max 2500 mm )
|
: 2507 mm
: 1250 mm
: 2.492,6 mm
: 6 mm
: 14,4 mm
: 1 mm
: -
: 3,1 m2
: 9,6 kg/st
: 3,1kg/m2
: 174
: 1250 mm direction |
±
2 mm
± 1 mm
± 0,2 mm
± 01,5 mm
DIN
± 0,3 % on L
|
Treatments
     |
