Material
Aluminium AlMg1
|
|
|
|
|
|
|
|
0,30 |
0,45 |
0,05 |
0,15 |
0,7
1,1 |
0,10 |
|
|
Tensile
strength: 140 - 180 N/mm2
0.2 limit of elasticity :120 N/mm2
Surface
Anodisation : 20 micron
type : E6 EV1
Chemically treated
Natural colour - matt
Useable on 1 side
No anodisation points visible
Fire Resistance : non flammable ( DIN 4102 )
Polished stainless steel on request
| Measurements |
| |
|
tolerations |
Length
Width
Ridge height
Ridge length
Panel thickness
Squareness
Surface area
Weight
No. of ridges
Fold direction
|
:
2500 mm
: 1250 mm
: 4,8 mm
: 29,75 mm
: 0,8 mm
: -
: 3 m2
: 7 kg/st
: 2,3 kg/m2
: 84
: 1250 mm
direction
|
± 5
mm
±
1 mm
±
0,2 mm
±
0,2 mm
DIN
±
0,3 % on L
|
Treatments
     |
