Material
Aluminium AlMg1
|
|
|
|
|
|
|
|
0,30 |
0,45 |
0,05 |
0,15 |
0,7
1,1 |
0,10 |
0,20 |
- |
Tensile
strength: 140 - 180 N/mm2
0.2 limit of elasticity :120 N/mm2
Surface
Anodisation : 15 micron
type : E6 EV1
Chemically treated
Natural colour - matt ( other only 8 µ anodisation )
4 anodisation points with a diameter of ± 3mm visible
Finish
Hot rolled
Crossed simple oils
Fire Resistance : non flammable ( DIN 4102 )
| Measurements |
| |
|
tolerations |
Length
Width
Oil height
Panel thickness
Squareness
Surface area
Weight
|
: 2500 mm
: 1219 mm
: 1 mm
: 1,6 mm
: -
3 m2
13,5 kg/pc
4,5 kg/pc
|
±
2 mm
± 5 mm
± 0,2 mm
± 0,15 mm
± 0,3 % on L
|
Treatments
    |
